Model | WCBD 20H | |
Capacity | kg | 2000 |
Load centre distance | mm | 600 |
Max. Fork height | mm | 520/550/650/685 |
Fork length | mm | 1100/1150/1220 |
Min. Fork height | mm | 85 |
Fork width | mm | 205 |
Turning radius | mm | 1890/1940/2010 |
Travelling speed with load | Km/h | 5.8 |
Travelling speed wihout load | Km/h | 6.2 |
Drive wheel size | mm | Ф250 |
Load roller size | mm | Ф80 |
Voltage | V | 24 |
Net. Werght | kg | 360-400 |
